Membrane keypads for industry & medical technology

We man­u­fac­ture robust, sealed and indi­vid­ual or customer-​specific mem­brane key­pads with key emboss­ing, light­ing and a long ser­vice life – devel­oped and pro­duced to your requirements.

Available from small series — IP up to 67 — Made in Germany or Made in Asia

Membrane keypad with embossed keys and LED lighting

Robust & tight

Closed front, chemical-​resistant, easy to clean.

Individual

Design, key emboss­ing, win­dows, sur­faces — freely selectable.

Durable

>1 mil­lion oper­a­tions per but­ton — depend­ing on dome & material.

Budget-​friendly solutions

Prototyping & series pro­duc­tion in Germany or Made in Asia

Advantages of membrane keyboards

Hygienic & easy to clean

Closed sur­face with­out dirt trap — ideal for med­ical tech­nol­ogy, lab­o­ra­tory & food.

Design freedom

Print, col­ors, win­dow, emboss­ing and tac­tile feed­back freely customizable.

Protection classes up to IP67

Dust & water­proof thanks to suit­able seal­ing con­cepts and choice of materials.

Technology & structure

Key embossing

Round, rec­tan­gu­lar or frame emboss­ing for hap­tic guid­ance. Optionally with tac­tile snap domes for defined feedback.

Lighting

LED back­light, light guides and translu­cent win­dows for sta­tus indi­ca­tors or key illu­mi­na­tion.

Switching level

Printed con­duc­tor tracks, printed cir­cuit boards, flex­i­ble car­rier films, con­nec­tors and ESD con­cepts depend­ing on the application.

Surfaces & materials

Polyester films with dif­fer­ent hap­tics (glossy, matt, tex­tured), scratch-​resistant coat­ings and anti-reflection.
Membrane keypads

Areas of application

Medical technology

Hygienic front foils, resis­tance to dis­in­fec­tants, clear symbols.

Mechanical & plant engineering

Robust against dust, oil and vibra­tion — high availability.

Laboratory & Food

Easy to clean, IP pro­tec­tion, resis­tance to clean­ing agents.

Military

Reliable, pre­cise, durable and resis­tant to chem­i­cals and EMC shield­ing.

Rail Systems Engineering

Robust against vibra­tions and tem­per­a­ture fluctuations.

Indoor & Outdoor

For pro­tected indoor envi­ron­ments & also for demand­ing out­door appli­ca­tions.

Technical specifications

Feature

Typical value /​ option

Service life

>1 mil­lion presses per button

Protection class

Up to IP67 (on request)

Keys

Flat, embossed, with/​without tac­tile domes

Lighting

LED back­light, sta­tus LEDs, light guides

Materials

PET dif­fer­ently coated & printed

Projects & References

Selected exam­ples of cus­tomized mem­brane key­pads.

Medical technology

Medical tech­nol­ogy — embossed but­tons, IP pro­tec­tion, clear sym­bols, resis­tant to disinfectants

Membrane keypads - Mechanical engineering

Mechanical engi­neer­ing — robust sur­face, tac­tile domes, user-​friendliness

Military membrane keypads

Military — chemical-​resistant, easy to clean, robust and durable, with EMC shield­ing

What is a membrane keypad? (Briefly explained)

A mem­brane key­pad is a flat, closed input sys­tem . input sys­tem (HMI) in which switch­ing con­tacts and con­duc­tor tracks are printed on flex­i­ble foils. It is robust, easy to clean and can be cus­tomized in terms of design, key emboss­ing and light­ing — ideal for indus­try, med­ical tech­nol­ogy and hygien­i­cally sen­si­tive areas.

When is a membrane keypad the best choice?

Whenever a sealed front, easy clean­ing, water and dust pro­tec­tion (up to IP67) or a customer-​specific lay­out mat­ter – for exam­ple in med­ical or lab­o­ra­tory devices and in mechan­i­cal engineering.

Difference to the silicone keyboard?

Silicone key­pads offer three-​dimensional keys and good hap­tics, but are more exposed to dirt and liq­uids. Membrane key­pads are flat and sealed and there­fore more hygienic. In harsh envi­ron­ments with strict hygiene rules, the mem­brane key­pad has the advantage.

How is the feel achieved?

Through key emboss­ing (round or frame emboss­ing) and/​or tac­tile snap domes with a defined actu­a­tion force. This cre­ates a clear pres­sure point.

What is a realistic service life?

Typically >1 mil­lion actu­a­tions per key, depend­ing on mate­r­ial, dome type, envi­ron­ment and travel.

What types of protection are possible?

With suit­able seal­ing and a sealed front IP65–IP67 can be achieved. For higher require­ments, we advise on the design (front foil, frame, potting).

Lighting & displays?

LED-​Backlight, light guides and translu­cent win­dows for sta­tus indi­ca­tors and icons are com­mon. Brightness and uni­for­mity can be designed for the spe­cific application.

How does individualization work?

We clar­ify the oper­at­ing envi­ron­ment, num­ber of keys, lay­out, pro­tec­tion class and hap­tics. This is fol­lowed by design, sam­ples, val­i­da­tion and the start of series pro­duc­tion.

Are there minimum quantities?

Small series are pos­si­ble. We pro­vide trans­par­ent advice on tool­ing and set-​up costs and batch sizes.

Criterion

Folio key­board

Silicone key­board

Mechanical but­tons

Hygiene

Very good (closed front)

Good

Medium (open column)

Protection class

Up to IP67

IP54-​IP65

Depending on the housing

Haptics

Embossing + snap domes

Soft, rub­ber­ized

Pronounced (stroke)

Design free­dom

Very high (print/​layout)

High

Medium

Cleanability

Very good

Good

Medium

Terms & synonyms

Membrane key­pad, mem­brane key­pad, front key­pad, oper­at­ing foil, HMI key­pad, key­board foil, front foils, touch foils.

Frequently asked questions

Membrane key­pads are flat, sealed input sys­tems with printed switch­ing foils. They are robust, easy to clean and highly customisable.
When a key is pressed, two con­duc­tive lay­ers make con­tact. This cre­ates a sig­nal that reg­is­ters the keystroke.
Typical appli­ca­tions are indus­trial plants, med­ical devices, POS sys­tems, house­hold appli­ances, vend­ing machines and con­trol panels.
They are robust, water- and dust-​proof, very durable, easy to clean and can be indi­vid­u­ally designed.
Yes – LED back­light, light guides and var­i­ous types of emboss­ing are avail­able. Tactile domes pro­vide defined feedback.
Yes. Layout, colours, sym­bols, labelling, back­light­ing and even logos can be freely customised.
Mechanische Tastaturen haben physis­che Schalter pro Taste, Folientastaturen nutzen flex­i­ble Schichten ohne einzelne mech­a­nis­che Komponenten.
Yes. Feedback is pro­vided by so-​called snap domes (metal domes), which cre­ate a notice­able click.
Depending on the design, pro­tec­tion classes up to IP67 are pos­si­ble. We advise on the right seal­ing con­cept for your application.
Yes, they often reach mil­lions of actu­a­tion cycles and are very resis­tant thanks to their sealed surface.
Yes. They can be inte­grated with printed cir­cuit boards, touch­screens, dis­plays, light­ing and other con­trol elements.
